11-Port Gigabit Uplink PoE Switch With 30W PoE+ Power And Watchdog Function

PoE Ports : Ports 1-8

Forwarding Rate : 5.65Mpps

Jumbo Frame Support : 9.2K

MAC Address Table : 2K

Model Number : ONV-H1108PFD

Switching Capacity : 12Gbps

Operating Temperature : -20~55°C

Brand Name : ONV

Payment Terms : T/T,Western Union

Delivery Time : 2-8 work days

Place of Origin : China

Dimensions : 200*130*40mm

Max PoE Power : 30W per port

Port Count : 11 (8*10/100Base-TX RJ45, 2*10/100/1000Base-T RJ45, 1*1000Base-X SFP)

Certification : CE, FCC, RoHS

MOQ : 1

Supply Ability : 500000 pcs/month

Total PoE Power : 100W

Packaging Details : Packaging dimensions: 250*205*45mm, weight: 0.95kg, Carton dimensions: 490*440*270mm, 20 pcs/carton, weight: 20kg

Contact Now

11-port Gigabit Uplink PoE Switch

Product Overview

The ONV-H1108PFD is a Gigabit uplink PoE switch independently developed by ONV. It features 8×10/100Base-TX RJ45 ports, 2×10/100/1000Base-T uplink RJ45 ports, and 1×1000Base-X uplink SFP fiber port. Ports 1-8 support PoE+ power supply with single-port PoE power reaching 30W.

The PoE port supports watchdog servo function. When port communication fails, the corresponding port PoE automatically restarts to restore network communication without affecting other ports. As a PoE power supply device, it automatically detects and recognizes standard power-receiving equipment and supplies power through network cables.

It can power PoE terminal equipment such as wireless APs, IP cameras, VoIP phones, and video access control intercoms via network cable, meeting high-density PoE power supply requirements. Ideal for hotels, campuses, factory quarters, and small-to-medium enterprises. Unmanaged mode enables plug-and-play operation with no configuration required.

Technical Specifications

Model ONV-H1108PFD
Interface Characteristics
Fixed Port 2×10/100/1000Base-T RJ45 ports (Data)
8×10/100Base-T PoE ports (Data/Power)
1×1000Base-X uplink SFP fiber ports (Data)
Ethernet Port Ports 1-8: 10/100Base-T(X)
Ports 9-10: 100/1000Base-T(X) auto-sensing
Full/half duplex MDI/MDI-X self-adaption
Twisted Pair Transmission 10BASE-T: Cat3,4,5 UTP (≤250m)
100BASE-TX: Cat5 or later UTP (≤100m)
1000BASE-T: Cat5e or later UTP (≤100m)
Optical Fiber Port No optical module included by default (optional single-mode/multi-mode, single fiber/dual fiber optical module, LC)
Optical Cable/Distance Multi-mode: 850nm/0-550m
Single-mode: 1310nm/0-40km, 1550nm/0-120km
Function Switch E file: Long-distance and VLAN isolation (Default-OFF, enable-ON). When enabled, ports 1-8 support 10M/250m transmission and VLAN isolation
Chip Parameters
Network Protocol IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE802.3x
Forwarding Mode Store and forward (Full wire speed)
Switching Capacity 12Gbps (non-blocking)
Forwarding Rate@64byte 5.65Mpps
MAC 2K
Buffer Memory 2M
Jumbo Frame 9.2K
LED Indicator Power: PWR (Green)
Network: Link (Green)
Function switch: Extend (Green)
PoE & Power Supply
PoE Port Port 1-8
Power Supply Pin 1/2(+) 3/6(-)
Max Power Per Port 30W, PoE+
Total PWR/Input Voltage 100W/(AC100-240V)
Power Consumption Standby <5W, full load <100W
Power Supply Built-in power supply, AC100~240V 50-60Hz, 2.2A
Physical Parameters
Operation Temp/Humidity -20~55°C, 5%~90% RH non-condensing
Storage Temp/Humidity -40~80°C, 5%~95% RH non-condensing
Dimension (L×W×H) 200×130×40mm
Net/Gross Weight 0.65kg/0.95kg
Installation Desktop, Wall mount
Certification & Warranty
Lightning Protection Lightning protection: 4KV 8/20us, Protection level: IP30
Certification CE mark, commercial, CE/LVD EN62368-1, FCC Part 15, RoHS
Warranty 1 year, lifelong maintenance

11-Port Gigabit Uplink PoE Switch With 30W PoE+ Power And Watchdog Function

Key Features

100M Access with Gigabit Uplink RJ45/SFP Ports

  • Support for non-blocking wire-speed forwarding
  • Full-duplex based on IEEE802.3x and half-duplex based on Backpressure
  • RJ45 ports and Gigabit SFP ports for flexible networking across various scenarios

Smart PoE Power Supply

  • Compliant with PoE+ power standard
  • Automatically identifies PoE devices for power without damaging non-PoE devices
  • 8×10/100Base-TX RJ45 ports support PoE power for security field applications

Innovative Functions

  • PoE Watchdog: Enabled by default for ports 1-8, automatically detects data communication status in real-time and restarts PoE when communication fails
  • Long Distance + VLAN Mode (E): When enabled, ports 1-8 operate at 10Mbps with maximum transmission distance up to 250 meters and physical VLAN isolation

Stability and Reliability

  • CQC, CE, FCC, RoHS certifications
  • Plug-and-play operation with no configuration required
  • User-friendly panel with LED indicators for PWR, Link, and PoE status
  • Low power consumption, galvanized steel housing with excellent heat dissipation

Dimensions

11-Port Gigabit Uplink PoE Switch With 30W PoE+ Power And Watchdog Function

Ordering Information

Model Description Built-in Power Supply
ONV-H1108PFD PoE switch with 8×10/100M RJ45 ports, 2×10/100/1000M RJ45 ports, and 1×1000M uplink SFP fiber port. Ports 1-8 support PoE+ standard with PoE watchdog (auto-restart PoE). Adjustment function switch enables 10M/250m transmission and VLAN isolation for ports 1-8. 52V/100W

Note: Optical module and mounting ear are not included and need to be purchased separately.

Packing List

Packing List Qty Unit
11-port Gigabit uplink PoE switch 1 Set
AC Power Line 1 PC
User Guide 1 PC
Warranty Card and Certificate of Conformity 1 PC

Optical Module Options

Product Model Description Unit
1.25G Optical Module 2630 SFP optical module, 1.25G multi-mode dual fiber 850nm, transmission distance: 550m, LC interface. Supports DDM function and hot plugging. PC
2632 SFP optical module, 1.25G single-mode dual fiber 1310nm, transmission distance: 20km, LC interface. Supports DDM function and hot plugging. PC
2612-T SFP optical module, 1.25G single-mode single fiber TX1310nm/RX1550nm, transmission distance: 20km, LC interface. Supports DDM function and hot plugging. PC
2613-R SFP optical module, 1.25G single-mode single fiber TX1550nm/RX1310nm, transmission distance: 20km, LC interface. Supports DDM function and hot plugging. PC
2612-T-SC SFP optical module, 1.25G single-mode single fiber TX1310nm/RX1550nm, transmission distance: 20km, SC interface. Supports DDM function and hot plugging. PC
2613-R-SC SFP optical module, 1.25G single-mode single fiber TX1550nm/RX1310nm, transmission distance: 20km, SC interface. Supports DDM function and hot plugging. PC
